CMITECH BMT-20 Dual Iris Scanner

CMITECH BMT-20 Dual Iris Scanner

₹22,800 — In stock · Brand: mTm

Buy CMITech BMT-20 Dual Iris Scanner for Aadhaar enrolment, biometric ID and large-scale iris capture. Binocular design, USB powered, IP64 rated and easy to use.

CMITECH BMT-20 Dual Iris Scanner Aadhar Enrolment Kit The CMITech BMT-20 is a binoculars-type iris biometrics imaging device that quickly captures highest quality iris biometric images. Exceeding industry standards for image quality, this system optimizes matching accuracy, essential in very large scale deployments for which de-duplication is a core deliverable. Easy to use, the system can be reliably positioned by the subject with minimal instructions, or by an operator with the aid of positioning feedback LEDs on the top of the imager’s housing. The patentpending optical design of the BMT-20 includes expanded depth of field and a very large interpupillary distance range, providing effortless capture for subjects of all ages. Intended for applications in which subjects have limited prior experience with biometrics devices, the BMT-20 is ideal for enrollment programs of all sizes, including those involving very young children. Designed with the latest in optical and system control technology by one of the leaders in the industry, the BMT-20 is physically robust, highly reliable and durable. This system meets the elevated IP64 intrusion protection standard and is sealed against dust and other airborne particles to provide extended life in harsh environmental conditions. CMITech’s products and technology are leading the industry in cost effective and easy to use iris recognition solutions serving the full range of identification and authentication use cases, including physical and logical access control, national identity, law enforcement, border crossing and immigration control applications. Lowest Wholesale Price on CMITECH BMT-20 Dual Iris Scanner. Buy in bulk from mTm Store Wholesale Marketplace, Nehru Place, and get the best market rates, genuine products, and exclusive volume discounts.

Specifications

Dimensions219 x 161 x 58 mm (8.6 x 6.3 x 2.3 inches)
Unit weight680 g (1.5 lbs)
Image outputMeets or exceeds ISO 19794-6 standard
MTF / spatial resolutionExceeds 4.0 lp/mm @ > 60% contrast
Pixel resolution18.4 to 20 pixels/mm
Iris image pixel resolution640 x 480 pixels
Optical path distance350 to 380 mm
Depth of field30 mm (1.2 inches)
Inter-pupillary distance range40 to 90mm (1.6 to 3.5 inches)
Time of captureTypically around 0.5 second, from time of proper head placement
IR illumination for iris imagingDual LED: wavelengths of 850 nm nominal (about 60%); and 750 nm nominal (about 40%)
Internal LED for pupil contractionBroadband visible (white)
External LED indications for operator assisted positioningRed: Device position is too high Blue: Device position is too low Green: Device position is OK White: Image capture in progress
Operating temperature range0 to 50˚C
Humidity10 to 90% RH, non-condensing
Eye safety standardIEC 62471, IEC 60825-1
Ingress protectionIP64
InterfaceUSB 2.0 High Speed
PowerUSB 2.0 (500 mA at 5V) No additional power required
PC hardware requirementsPC/x86 platform: Intel® Atom™ or above processor ARM: Cortex A9 quad core processor
OS compatibilityWindows 7, 8, 8.1 and 10 (32 and 64 bit) Linux Ubuntu 12.04 distribution Android 4.0 and above
Other certificationsCE , FCC, USB-IF, India STQC, RoHS, WHQL
